1/4” X 12’ Cincinnati Model 2CC12 Mechanical Power Squaring Shear
1/4” X 12’ Cincinnati Model 2CC12 Mechanical Power Squaring Shear
Description
(1) Pre Owned Cincinnati Model 2CC12 Mechanical Power Squaring Shear
GENERAL SPECIFICATIONS:
Capacity : ¼”
Distance Between Housings 144 3/4”
Back Gage Range 0 - 48”
Rake Taper ¼” PER FOOT
Strokes Per Minute 60
Hydraulic Hold Downs 13
Hydraulic Hold Down Force 8 TONS
Distance Under Hold Downs½”
Knife Size 1” X 3” X 126”
Throat 4”
Main Motor Horsepower: 15 HP 460V3/60
EQUIPPED WITH:
Cincinnati 2CC12 Conveyor
120” Front Squaring Arm
Dovetail Slots In Shear Table
Hand Slots in Shear Table
Electric Foot Switch
Air Electric Cylinder Jaw Clutch
Automatic Pressurized Lubrication
Interlocked All Steel Construction
Non-Float Inclined Ram
Approximate Overall Weight 19,800 LBS
